Product Description

Communication Cable wire Extrusion Line

1. APPLICATION:
Communication Cable Extrusion Line is high production line, It's used for the copper wire insulation coating, then the wire get cooling through water to finished products. The product can be power cable, automotive wire, communication cable, electronic wire, magnetic wire, LAN cable and so on.

2. CONSISTING COMPONENTS

1. Portal type Pay off stand
2. Caterpillar
3. Main extruder
4. Automated loader & dryer
5. Manual centering Crosshead
6. Moving trough
7. Single layer main cooling trough
8. Water wiper
9. Digital Diameter controller
10. Mark printer
11. Caterpillar
12. Spark tester
13. Meter counter
14. Portal type Take up
15. Control box

3. MAIN PARTS BRAND
1. Motor: Germany-Siemens
2. Inverter: Germany-Siemens or YASKAWA Japan
3. Electric equipment: Siemens and Omron
4. Bearing: NSK from Japan
5. Belt: Mitsubishi

4, TECHNICAL PARAMETER:
1. Name: Communication Cable Extrusion Line
2. Power: 380V, 50Hz three phase or customer's requirement
3. Main motor power: 130kw
4. Finish wire diameter: 8.0— 80 mm
5. Temperature control: 11 zones
6. Max Line speed: 90m/min
7. Rotation speed: 95 rpm/min
8. Max accumulating length: 200m
9. Extrusion capacity: 650 kg/h
10. Bobbin dia.: 1000-2000mm

5, MAIN PARTS FUNCTION:
1. Inverter: The speed can be changed from zero to max
2. Pay-off tension: Control automatically by electricity
3. Take-up machine uses Polish rod, transverse and distance can be adjusted by plain shaft.
4. Machine center height: 1 meter
5. Diameter of screw: 120mm, L/D of screw: 26/1. Material: 38 CrMoAiA,
6. The surface of screw is carburized and quenched, electroplated with hard cr.
7. Inside diameter of screw tube: 120mm. Material: 38 CrMoAiA,
8. The surface is carburized and quenched.
9. The material of insulation are PVC, XLPE, LSHF, PE, PP, TPEE, NYLON
10. Production direction: Pay-off on the left. Take-up on the right. Customer's requirement
11. Color of production line is light blue(automobile finish ), safe cover is yellow OR customer's requirement
12. PROMOT SWITCH counter, set length freely.
13. Automatically stop: When the counter has reached to your desired length, the Take up will stop automatically, if wire breaks abnormal and self-actuating brake.
